AA710 Wireless Remote Control and Counter
$2,220.00 excl. GST/VAT
AA710 Wireless Remote Control and Counter — FOR WINDLASSES, THRUSTERS, DAVITS, DECK LIGHTS, ANCHORWASH
The Muir AA710 Wireless Remote Control and Counter gives you full control from anywhere on the boat. With the AA710 Wireless Remote Control and Counter, you can see at a glance the length of anchor rode deployed.
Functions:
A system with one base station (6 outputs) using the AA710 Wireless Remote Control and Counter can operate:
- 1 windlass plus a deck wash and deck light or other auxiliary functions
- or 1 windlass and 1 or 2 thrusters
Kit Includes:
- 1 console, 1 base station, 1 sensor, 1 magnet, load sensing connectors, installation and operation instructions. Additional consoles, base stations and antennas sold separately.
Order the AA710 Wireless Remote Control and Counter from Muir Australia — trusted marine engineering since 1968.
FEATURES:
- Full windlass control and chain counting
- Controls bow and stern thrusters independently and together
- Preset the length of rode to deploy
- Auto stop and docking alarm when the anchor is close to docking
- Works with rope/chain or all-chain rode
- Logs windlass operating hours for maintenance
- Easy installation and set up on most windlasses
- Plug and play sensor installation
- Console unit is shockproof, waterproof and will float
- High level wireless transmission security with unique ID
- Safety lock reduces unwanted operation
- Ergonomic shape with rubber grip for wet conditions
- Console holder and protective cover
- Displays signal strength and battery level
- Use with DC, AC, Hydraulic and drum windlasses
- Operates in parallel with other control equipment
eg toggle switches, foot switches and other electronic controllers - outputs in the base station – A single kit can be used for 1 windlass plus a bow and stern thruster
- Antenna plug is standard on the base station
- Automatic sensor detection – no need to select sensor in the set up
- Manual control alarm and stop at docking distance – stops the windlass during retrieval when using
manual and automatic operation - Swap controls option in set up – this option means the Up button can be used as Out
and the Down button can be used as In - Time out connection between the base station and the console now adjustable up to 20 minutes
- Dual speed windlass capability
- Options for windlass related actions, using the left and right arrow buttons – user selected and could
include a windlass stow, power cleats, deck wash, deck light - Power enable option now available with off delay for hydraulic, AC, DC and PLC installations
AUTOANCHOR 710 WIRELESS REMOTE CONTROL AND CHAIN COUNTER
TECHNICAL SPECIFICATIONS
| Power Supply | 2 X AA1.5V Batteries(RMS) |
| Current Consumption | N/A |
| Output Maximum Current Draw | N/A |
| Output Minimum Current Draw | N/A |
| IP Rating | IP67 |
| Operating Temperature | 23oF to 140oF (-5oC to 60oC) |
| Wireless Transmission | 2.4GHz ISM Band, IEEE 802.15.4 Compliant, 64 Bit Unique ID |
| Wireless Range | Typical Minimum 10m (30ft). Range depends on installation |
| Default Safety Cut Out | 5 minutes after last key touch |
| Outputs | 6 |
| System Supports | Up to 3 base stations and 3 consoles |
| Rode – Chain Only | Stainless or galvanised steel |
| Rode – Rope and Chain | Must have a minimum of 10ft (3m) of galvanised steel chain. Rope should be a good quality nylon anchor rope. Type 66 or equivalent |
| EMC Protection/CE | EN60945 |
For DC windlasses a dual direction solenoid is required.
Package Inclusions
AA710 Kit Includes::
- 1 console
- 1 base station
- 1 sensor with 2m cable
- 1 magnet
- Load sensing connectors
- Installation and operation instructions
