Drawings
Top View
Features
- Equipped with a folding retaining arm that allows minimal space and easy storage.
- Fully dismountable/portable design.
- Free rotating lower axle and a manual press wheel, eliminating the need for light pulling on the rope.
- Perfect for pulling traps for crab, shrimp, lobster etc.
- Stainless steel mounting bolts
- Installation/Operation booklet
Included in the package
Circuit Breaker & Mounting Pannel
Deck Switch
Deck mounting studs & fasteners
Installation/Operation booklet
| Name | Specifications |
|---|---|
| Recommended Vessel Length | 11-m |
| Power Supply Options | DC 12V |
| Recommended Muir Circuit Breaker | 100A (12V) |
| Motor (Watts) | 900Watts |
| Amps Workload | 120A (12V) |
| Max Load | 90Kg |
| Workload | 18Kg |
| Max Line Speed | 35m/min |
| Compatible Rope Sizes | 4-10mm (2/25″ – 3/8″) |
| Auto Anchor Compatible | Yes |
| Net Weight DC | 13.7Kg |
