HR 11000 Mega Horizontal Windlass | Vessels 42-54m (138-177ft)
Built for vessels between 42 and 54 metres (138-177ft), the HR 11000 combines Muir’s precision engineering with the heavy-duty capacity today’s superyachts and large commercial vessels demand. Its horizontal configuration keeps the drive mechanism enclosed above deck, an advantage where space below deck is at a premium.
Rated to a maximum pull of 5000kg, the HR 11000 delivers a continuous pull of up to 3202kg on the hydraulic variant (2600kg on the 50Hz AC drive), with retrieval speeds up to 20m/min. It’s available in 50Hz AC or hydraulic drive, giving specifiers flexibility to match the windlass to the vessel’s onboard power system.
The HR 11000 accepts short link chain up to 22mm and stud link chain up to U2-20.5mm, with a 356mm brake for secure chain holding under load. As with the rest of Muir’s Mega Line, it’s designed and manufactured in Australia to ISO9001 standards, built to perform in the demanding environments the superyacht and commercial marine industry requires.
For full technical drawings and package inclusions, see the specifications below or download the Mega Catalogue.
Drawings
Main View
Brake Options
Top View Standard Brake
Top View 35 Deg Brake
Inline Hydraulic
Right Hand Hydraulic
Included in the package
Technical Specification
| Name | Specifications |
|---|---|
| Recommended Vessel Length | 42-54m |
| Recommended Vessel Length (ft) | 138 - 177ft |
| Maximum Pull | 5000Kg |
| Continuous Pull | 2600Kg |
| Minimum Speed | 10m/pmin |
| High Speed | 20m/pmin |
| Input Power | 7.5Kw |
| Short link up to | 22mm |
| Stud link up to | U2-20.5mm - U3-19mm |
| Brake Size | 356mm |
| Average Weight (kg) | 536Kg |
| Right Hand Gearbox | Planetary |
| Inline Gearbox | Planetary |
| Name | Specifications |
|---|---|
| Recommended Vessel Length | 42-54m |
| Recommended Vessel Length (ft) | 138 - 177ft |
| Maximum Pull | 5000Kg |
| Continuous Pull | 3202Kg |
| Minimum Speed | 10m/pmin |
| High Speed | 20m/pmin |
| Hydraulic Flow | 30 l/pmin |
| Maximum Flow | 60 l/pmin |
| Pressure | 170 bar |
| Maximum Pressure | 200 bar |
| Short link up to | 22mm |
| Stud link up to | U2-20.5mm - U3-19mm |
| Brake Size | 356mm |
| Average Weight (kg) | 450Kg |
| Right Hand Gearbox | Planetary |
| Inline Gearbox | Planetary |
